Clear Tablet Screen Protector Product Specification
|
Product |
2.5D Clear Tablet Tempered Glass |
||
|
Materials |
Glass |
0.33mm High Alu Glass |
|
|
AB Glue Thickness (120um) |
OCA 40um |
||
|
PET 50um |
|||
|
Silicone 30um |
|||
|
Fingerprint Oil |
Electroplating |
||
|
Procduct Specs |
|
<— Electroplating layer 0.33mm High Alu Glass layer <— 0. 115mm Clear AB Glue layer <— 0.05mm Pet layer |
|
|
Processing |
Thickness |
Glass: 0.33mm |
|
|
Product: 0.45mm ±0.02 |
|||
|
Edge |
Edge≥35c |
||
|
Transmittance |
≥92% |
||
|
Hardness |
9H |
||
|
Tempered Time |
4 Hours |
||
|
|
|
||
|
Testing Items |
Standard |
||
|
Capability Testing |
Sticking Testing |
The Dimensions match precisely,with no signficant obsrucion to the viewing window or inferference with the normal function of all sensing holes |
|
|
Excellent exhaust performance, strong adsorption capacity, and bubble-free operation |
|||
|
The edge is not irritating to the skin |
|||
|
Seamless |
|||
|
Touch sensitivity testing |
No issues affecting touch functionality |
||
|
Transmittance testing |
≧92% |
||
|
Resilience Testing |
Bend 90 degrees,no broken |
||
|
Drop Testing |
Drop: 64G/60CM drop ing 3 times,no broken |
||
|
Edge pressure testing |
15kg above |
||
|
Hardness testing |
9H |
||
|
Water Angle Testing |
Testing 3000 times ≥105° ±2 |
||
|
Temperature Testing |
After exposure to temperatures of 80℃ (high) and 40℃ (low) for a continuous period of 48 hours, no bubbles |
||
